Paving Stone Lifter

Product Code: APSL

General

The Aardwolf Paving Stone Lifter revolutionizes paving projects with strength, safety, and precision. Equipped with an automatic vacuum pressure system, it ensures reliable operation with real-time feedback. Users can choose between handle-mounted buttons for direct, or body-mounted controls for broader operational flexibility. Designed for versatility, it accommodates manual use, forklift support, or crane hook attachment, making it the perfect solution for various lifting needs.

Key Features

Automatic Vacuum System: Provides safe operation with real-time visual and audio feedback.
Dual Controls: Handle-mounted for precision or body-mounted for wider accessibility.
Quick-Fit Pads: Simplifies setup and material adaptation for faster transitions.
Disassemblable Stand: Easy to transfer for various lifting needs.
Versatile Operation: Supports manual use, forklifts, or cranes.
High Capacity: Lifts up to 120 kg (264.5 lbs).
Efficient Battery: Powered by a 24V-8Ah battery for quick maintenance and extended usability.

Specifications

Metric

Imperial

Pad sizes
with W.L.L

276 x 176 mm: 60 kg

246 x 146 mm: 40 kg

186 x 86 mm: 14 kg

10.9'' x 6.9'': 132.3 lbs

9.7'' x 5.7'': 88.2 lbs

7.3'' x 3.4'': 30.9 lbs

Battery information for the device

Battery capacity	24VDC-8Ah
Non-stop working time	4 hours

Motor information

Vacuum flow rate	38 liters/minute
Motor	24VDC - 2A
